Professional 32 channel IP recorder NVR. Compatible with all ISON cameras. Supports remote viewing option from smartphone as well as remote viewing option of recording archive from smartphone or computer. Supports all types of Internet, cameras with built-in microphone, with electronic optical zoom, PTZ control. Latest generation processor. High quality ISON brand! Official warranty 3 years.
ISON-NVR32S video recorder characteristics:
- 32-channel IP video recorder NVR;
- Supports ip cameras up to 12 megapixel resolution;
- ISON-GO-Autostart-Technologie (wird bei Stromausfall nicht zurückgesetzt);
- Compatible with all ISON IP cameras;
- Supports cameras with built-in microphone;
- Supports CCTV cameras with zoom;
- Supports rotating PTZ cameras;
- Support for cameras with motion sensors;
- Supports work with 3g/4g modems (for connection you need router);
- Support remote viewing from iPhone, iPad, Android, Android PAD smartphone;
- Availability of the function of sending e-mail messages in case of motion sensor operation;
- Recording an archive up to 180 days (with maximum hard disk);
- Supports 25fps recording Echtzeit
(Objekte in Bewegung sind nicht unscharf); - HDD auto overwrite function (When the HDD is full, recording does not stop, overwrite starts automatically);
- Unterstützt RTSP-Stream, Cloud-Aufnahme, Aufnahme auf entferntem Rekorder oder Server;
- Möglichkeit, das Archiv aus der Ferne über das Internet herunterzuladen;
- USB data copying capability;
- Integrierter Programmzoom (Möglichkeit, Objekte während der Betrachtung zu vergrößern);
- GPU Class: P-12
- ISON TURBO synchronization mode;
- Matrix type: PFE-PREMIUM;
- ISON-DIA Technologie;
- Intelligent Cabling;
- Energy Class 89HD;
- Core: 15ISQ;
- Die Garantie von ISON beträgt 3 Jahre.
- Main Processor Quad Cortex A53
- Operating System Embedded LINUX
- Video Input 32ch(12MP/8MP/6MP/5MP/4MP/3MP/1080p/1280×1024/960p/720p/D1/CIF) Output 1*HD,1*VGA
- Audio Input 1 Port RCA, support 32CH IPC audio input
- Output 1 Port RCA(Linear, 1kΩ), HD output
- Audio Bit Rate 64kbps
- Audio Compression standard G711U, G711A, AAC, MP2L2
- Intercom support (two-way)
- Alarm Sensor Input 16CH Output 4CH
- Motion Detection 32Channel, MD Zones: 396 (22 × 18)
- Trigger Events Recording, Email, FTP, Snapshot and Screen Tips, Pop-up Window, Buzzer, Notify Surveillance Center,
- Alarm Output
- Display HD Output1 4K(3840*2160)/2K(2560*1440)/1920*1080/1280*1024/1280*720/1024*768
- VGA 1920*1080/1280*1024/1280*720/1024*768
- Display Split 36CH/25CH/17CH/16CH/13CH/10CH/9CH/8CH/6CH/4CH/2CH/1CH
- Digital Zoom YES
- OSD Camera Title, Time, Recording, Motion Detection, Event Alarm
- Recording Video Compression H265/H264/H265+/H264+
- Resolution 12MP(4000*3000),8MP(3840×2160),6MP(3072*2048),5MP(2592×1944),4MP(2688×1520/2560×1440),3MP(2048×1536) ,1080P(1920×1080),1280×1024,960P(1280×960),720P(1280×720),960H(960×480),D1 (720×576/720×480)
- Record Rate PAL: 12MP@32CHx25fps,8MP@32CHx25fps,5MP@32CH×25fpss,4MP@32CHx25fps,3MP@32CH×25fps,1080P@32CH×25fps, 960P@32CH×25fps,720P@32CH×25fps, D1@32CH×25fps
- NTSC: 12MP@32CHx30fps,8MP@32CHx30fps,5MP@32CH×30fps,4MP@32CH×30fps,3MP@32CH×30fps,1080P@32CH×30fps, 960P@32CH×30fps, 720P@32CH×30fps, D1@32CH×30fps
- Record Mode Manual\Timer\Motion Detection\ Alarm\Smart Event
- Playback & Backup Local Sync Playback 2CH 12MP@30fps,4CH 8MP@30fps,6CH 5MP@30fps,8CH 4MP@30fps, 16CH 1080P@30fps, 16CH 960P@30fps, 16CH 720P@30fps,16CH D1@30fps
- Decode Capability 1080P(1920×1080)@480fps
- Remote Sync Playback YES
- Search Mode ALL, Timing Video, Motion Detection, Alarm,Tag search,Smart Event,Pictrue,Log
- Playback Functions Play, pause, fast forward, rewind, previous frame, next frame, electronic zoom, clip, audio
- Backup Mode USB Device/Network
- Network Interface 2xRJ45 10M/100/1000MAdaptive Ethernet Interface
- Incoming Bandwidth 320Mbps
- Outgoing Bandwidth 160Mbps
- Network Functions IPv6, TCP/IP, HTTP,HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE Onvif Profile S, Profile T
- Web Browser Edge, IE8-11, Google Chrome , Firefox ,Safari
- CMS Software Support Windows 7/ Windows 8/Windows 10/Windows 11/MAC OS
- Cloud Support Yes
- Smart Phone iPhone, Android
- Storage Interface Type 4 SATA Hard Disk Interface (3.5" SATA)
- Capacity Up to 10 TB capacity for each HDD
- General Language UI Simplified Chinese, Traditional Chinese, English, Polski, Czech, Arabic, German, French, Portuguese, Spanish, Italian, Hungarian, Korean, Dutch, Greek, Janpanese, Ukrainian, Kazakh
- USB Interface Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
- RS485 1port
- Power consumption 100-240VAC , 50/60Hz ≤20W (Without Hard Disk)
- Working Environment -10℃～50℃, 10%～90%(humidity)
- Product Dimension(W×D×H) 440mm × 372mm × 69mm
- Net Weight 4.38kg (without HDD)
- Gross Weight 5.68kg(without HDD)
Composition of the set:
- Video recorder
- DVR power supply unit
- USB mouse
- Packing box
