Descripción
Professional video recorder for video surveillance systems. Compatible with all ISON cameras. Supports video surveillance cameras up to 5 megapixels. Supports remote viewing option from smartphone as well as remote viewing option of recording archive from smartphone or computer. Supports all types of Internet, cameras with built-in microphone, with electronic optical zoom. Latest generation processor. High quality ISON brand! Official warranty 3 years.
ISON DVR08L video recorder characteristics:
- Tecnología de arranque automático ISON-GO (no se reiniciará cuando se produzca un fallo de alimentación);
- Clase de GPU: P-12
- Modo de sincronización ISON TURBO;
- Tipo de matriz: PFE-PREMIUM;
- Tecnología ISON-DIA;
- Cableado inteligente;
- Clase energética 89HD;
- Núcleo: 15ISQ;
- Transmisión en directo: UGT
- Multiplicador exprés de clase;
- Admite los códecs H264/H265;
- Se adapta a cualquier velocidad de Internet;
- Software gratuito de visión remota;
- Admite cámaras con micrófono incorporado;
- Función de sobrescritura automática del disco duro (cuando el disco duro está lleno, la grabación no se detiene, la sobrescritura se inicia automáticamente);
- Admite cámaras de CCTV con zoom;
- Soporte para cámaras con sensores de movimiento;
- Soporta el trabajo con módems 3g/4g (para la conexión necesita router);
- Zoom de programa incorporado (posibilidad de ampliar objetos durante la visualización);
- Soporta cámaras AHD e IP de 1,2,3,4,5 megapíxeles;
- Procesador CORTEX PRO de nueva generación;
- Reproducción simultánea de todos los canales con la máxima resolución sin pérdidas;
- Disponibilidad de la función de envío de notificaciones sobre alarmas de sensores de movimiento al correo electrónico;
- Disponibilidad de la función de visualización remota desde un teléfono (iPhone, iPad, teléfono Android);
- Salidas de vídeo: HDMI, VGA, USB, Audio;
- Admite cámaras giratorias con protocolo RS485;
- Graba hasta 180 días (con el disco duro al máximo);
- Color de la caja: negro;
- Disponibilidad de la propia nube gratuita de Bitvision:
- La garantía de ISON es de 3 años.
- Main Processor MC6630
- Operating System Embedded LINUX
- Video Input Analog: 8*(TVI/AHD: 5M@12fps; AHD/TVI/CVI: 4M@15fps; AHD/TVI/CVI: 1080P/720P@30fps; Analog: 960H) Analog+Network: 2*Analog (5MP)+7*network (MAX 5MP),4*Analog(5MP)+5*network (MAX 5MP),6*Analog(5MP)+3*network(MAX 5MP)
- Network: 16*5MP/4MP/3MP/1080P/960P/720P(Total incoming bandwidth ≤48M)
- Input 8CH BNC
- Signal Type Analog/AHD/CVI/TVI 2.0/TVI 3.0/Network
- Output 1HD,1 VGA
- Audio Input 1 ChannelRCA,support AOC
- Two-way Audio NO
- Output 1 Channel RCA
- Motion Detection 8 Channel (max 16 Channel in pure network mode)
- Trigger Events Recording, Email, Screen tips, Buzzer, Push notifications(motion detection)
- Email Alarm Send Image to The Designated E-mail
- AI Function Human Detection YES
- Protocol Coaxial Control
- Display VGA Resolution:1920 × 1080P, 1280 × 1024 , 1280 × 720,1024 × 768
- HD Output Resolution:1920 × 1080P, 1280 × 1024 , 1280 × 720,1024 × 768
- Display Split 1/4/8/9/16
- Privacy Masking 3 Rectangular Zones (Each camera)
- OSD Camera title, Time, Video loss, Motion detection, Recording
- Recording Video Compression H.265/H.265+/H.264/H.264+
- Audio Compression G.711U/G.711A
- Resolution 5MP_Lite(1280×1952), 4MP_Lite(1280×1440),1080N(960×1080),720P(1280×720),960H(960×480)
- Video Quality Lowest/Low/Ordinary/Good/Better/Best
- Record Rate Analog: PAL: 5MP_Lite(1296×1944 8*6fps),4MP_Lite(1280×1440 8*8fps),1080N(960×1080 8*15fps),720P(1280×720 8*15fps), 960H(960×480 8*25fps)
- NTSC:5MP_Lite(1296×1944 8*6fps),4MP_Lite(1280×1440 8*8fps),1080N(960×1080 8*15fps),720P(1280×720 8*15fps), 960H(960×480 8*30fps)
- Pure IP(H.265):
- PAL: 5MP@8×25fps,4MP@12x25fps,3MP@12×25fps,1080P@16×25fps,960P@16×25fps,720P@16×25fps,D1@16×25fps
- NTSC: 5MP@8×30fps,4MP@12×30fps,3MP@12×30fps,1080P@16×30fps, 960P@16×30fps, 720P@16×30fps, D1@16×30fps
- Record Mode Manual\Timer\Motion Detection\Intelligent
- Decode Capability 2*1080P@30fps
- Sync Playback Pure Analog: 4CH 5MP Lite @6fps,4CH 4MP Lite @8fps,4CH 1080P Lite@15fps,4CH 720P@15fps
- Mixture mode: 1CH 5MP@30fps,4CH 5M_Lite @6fps,4CH 1080P_Lite@15fps
- Pure Network: 1CH 5MP @30fps,1CH 4MP @30fps,2CH 1080P@30fps,4CH 720P@30fps
- Remote Playback 4 Channel / 1Channel
- Search Mode ALL, Channel, Manual, Time, Date, Motion Detection,Human Detection,Tag
- Playback Functions Play; Pause; Stop; Fast play; Slow Play;Rewind; Next File; Previous File; Next Camera; Previous Camera;
- Full Screen; Backup Selection; Digital Zoom
- Smart Phone Playback 4 Channel
- Backup Mode USB Device(with fomat FAT 32 )/Network/FTP
- Network Interface 1 RJ-45 10M/100M self-adaptive Ethernet Interface
- Network Functions TCP/IP,HTTP,HTTPS,SMTP,DHCP,FTP,DDNS,RTP,RTSP,RTCP,NTP,UPnP
- DDNS Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES,
- ZEBEYE,HDPROVN,DYNAMIC_PLANET,EASY_PLANET
- Web Browser Edge,IE8-11, Google Chrome , Firefox ,Safari
- CMS Software Support Windows 7/ Windows 8/Windows 10/Windows 11/MAC OS
- Extra Stream CIF/D1(1-30fps)
- Smart Phone iPhone, Android
- Hard Disk Driver
- Interface Type 1 SATA Interface
- Capacity 1 SATA Hard Disk (2.5"/3.5" SATA, Up to 10TB)
- Language Simplified Chinese,Traditional Chinese, English, Polish, Czech, Thai, Hebrew, Arabic, Bulgarian, Japanese,German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, korean, Dutch, Greek, Vietnamese, Ukrainian
- UTC Control YES
- USB Interface 2 USB 2.0 Interfaces
- Power consumption DC 12V/1.5A ≤ 7W (without HDD)
- Working Environment -10~55℃/10~90%
- Dimension (W×D×H) 260* 23*43(mm)
- Weight 0.86Kg (Without HDD)
Composición del conjunto:
- Video recorder
- DVR power supply unit
- USB mouse
- Packing box
