Comutador PoE de 4 canais Comutador PoE de 4 canais ISON IPSW8030

Descrição

Professional high quality POE switch. Compatible with all ISON IP cameras.

Specifications:

• Power Supply Input AC 180-240V/50-60Hz;
• Power Supply Output DC 48V;
• The power consumption of the switch is 100W;
• Ports 1-4: 10/100Mbps with POE power;
• WAN1 Ports: 10/100/1000Mbps ;
• Distance Ports 1-4: 100m (EXTENDED to 200-250m);
• Distance WAN1 Ports: 100m;
• Recommended cable: Cat5/5e/6 standard network cable;
• Network Standards IEEE802.3/10BASE-T Ethernet IEEE802.3u/100BASE-TX Ethernet IEEE802.3x Flow Control, IEEE802.3az;
• The maximum size of a TCP fragment is 1536 bytes;
• List of MAC addresses of the 2000 POE switch IPPOE411;
• PoE standard IEEE802.3af;
• PoE power availability;
• PoE End-Span(1/2+;3/6-) power type;
• PoE af power consumption, (per port maximum 15.4W);
• Indicators on PoE ports Power: 4 green – POE power is available; Internet: 4 yellow – active Internet connection;
• Operating temperature is 0℃~55℃ (with humidity of 5-95%);
• The storage temperature is 40℃ ~ 70℃;
• POE power transmission range up to 250m (When using ISON cable);
• Dimensions of the switch (mm) 165*115*25.5.
• Overheat protection;
• Overvoltage protection;
• Short-circuit protection;
• Plug & Play (easy connection).
• 3 year warranty.
• 8 ports.
